As good as new Palletizer # 10-24570
This brand new loader is suitable for palletizing shrink pacs, trays or boxes on Euro (1200 x 800) or industrial pallets (1200 x 1000). The machine is from 2021. Further information is available on request.
| Execution | 1-lane infeed with manually adjustable railing |
|---|---|
| Pre-grouping for 2-module Robobox, with mat chain and centering frame | |
| Lifting mechanism with column and slide | |
| Automatic fall protection | |
| Pallet height measurement to optimize the loading process | |
| Gripper head | Steelroller 1,300 x 1,300 mm with motorized rotation |
| Intermediate layer | Inserter free-standing (vertically next to the machine) with magazine |
| Pallet transport | Roller-conveyor (3 sections before, in, after) |
| Safety | 1 safety circuit, protective fence with light curtain, muting and registration switch |
| Operation | 15" Colour-Touch-Screen |
| Electrics | NAD (480 V, 60 Hz) |
| Control Unit | Allen Bradley (Controllogix) |
Details
Number
10-24570
Product
Krones
Model
Modulpal Pro 2A
Performance
350 layers/h (nominal)
Equipment
Shrinkpack, Tray, Carton on Euro- and Industrial-pallet
Year
2021
Delivery
promptly
Batch
Composite scheme with intermediate layer
