Filler NEW # 30-24890
ecomac Gebrauchtmaschinen GmbH offers here a new Krones Filler Modulfill for the filling of beer. The capacity is 42.000 bottles/h refer to a 0,5l glass bottle. The filler is equipped with a crown corker. The pitch is 87mm. Most important to know, the machine has a lot of specail features, which are described in the specification.
This Krones filler is a new machine. The readiness of construction will be in November/December 2025. A warranty of 24 month is existing.
Further details are available on request.
| Condition | NEW |
|---|---|
| Ready construction | November/December 2025 |
| Warranty | 24 month |
| Make | Krones |
| Model | Modulfill HES 3600-130-87 |
| Pitch | 87mm |
| Capacity | 42.000 bottles/h refer to 0,5l |
| Running direction | Left - right |
| Filling product | Beer, 5,5g/l - 12°C temperature |
| Filling system | Electronic short-tube filling height system |
| Number of filling valves | 130 pieces |
| Crowner | Crown corker (Modulcrown-upperpart) |
| Number of crown station | 26 pieces |
| Equipment | Automatic fragment flush |
| Bottle shower | |
| Tubular ring bowl | |
| CIP cups | |
| Automatic probe adjustment | |
| Sieve in product inflow | |
| Crowner in flushing execution | |
| Special features | Foam cleaning |
| High pressure injection with pivoting arm, heating crowner | |
| Mersial-media manifold without rinsing, with greased bearings | |
| Conductivity measurement Endress+Hauser | |
| Automatic sampling system SCHÜTT - Simples | |
| Machine safety | Free standing fence with doors and windows in laminated safety glass |
| Control unit | Siemens S7 1500 (TIA) |
| Voltage | 400V |
| Frequency | 50Hz |
| Control cabinet | Separated - on machine in VA with doors |
| Operating | Touch B&R VisiWin 21,5" display |
| Language ENG/DE | |
| Lubrication | Central lubrication with rotary media manifold |
Details
Number
30-24890
Product
Krones
Model
Modulfill HES 3600-130-87 KK26
Performance
42.000 b/h
Equipment
Beer in 0,5l glass bottles with crown cork
Year
Ready construction Nov/Dec 25
Delivery
Dec 25
Batch
Angle
Direction
L-R
